- 0501099107
| ITEM | CODE | DESCRIPTION | QT |
|---|---|---|---|
| 001 | ASSY FRAME | ||
| 002 | SKEP ASSY | ||
| 003 | 0541055419 | SIDE SEMI MOUNTED BASKET | |
| 004 | 0541055433 | FRONT SEMI MOUNTED SKEP | |
| 005 | 0541055434 | REAR SKEP SEMI MOUNTED | |
| 006 | ELECTRICAL SYSTEM | ||
| 007 | PNEUMATIC SYSTEM | ||
| 008 | HYDRAULIC SYSTEM | ||
| 009 | 0531051603 | LIFTING CYLINDER 76.2 X 101.6 X 2260 X 2010 | |
| 010 | 0531051778 | TIP CYLINDER 76.2 X 101.6 X 2100 X 1640 | |
| 011 | 0521050201 | QUICK COUPLING | |
| 012 | 0521052222 | QUICK COUPLING | |
| 013 | 0501059638 | HYDRAULIC VALVE EL/PN ASSY | |
| 014 | 0501053835 | FEMALE QUICK COUPLER | |
| 015 | 0541057322 | HOSE KIT | |
| 016 | 0501053834 | MALE QUICK COUPLER | |
| 017 | 0521054629 | 25/26L WATER TANK | |
| 018 | 0541055416 | SEMI MOUNTED FRAME BASE | |
| 019 | 0541055019 | FLASHLIGHT SUPPORT | |
| 020 | 0541055417 | GUIDE FRAME WITH SEMI MOUNTED LIFTING | |
| 021 | 0511047914 | LIFT ASSY | |
| 022 | 0521044694 | LEFT ROCKER ARM | |
| 023 | 0521050366 | LEFT AND RIGHT BALANCE SHEET | |
| 024 | 0511045858 | WHEEL HUB ASSY WITH BRAKE | |
| 025 | 0541057288 | LEFT WHEEL | |
| 026 | 0521044693 | SEMI MOUNTED RIGHT REGULATOR ROCKER | |
| 027 | 0521050367 | ADJUSTABLE ROCKER 200MM | |
| 028 | 0511048317 | HITCH BALL REAR | |
| 029 | 0503061865 | WHEELS AND TIRE | |
| 030 | 0511048316 | HITCH BALL FRONT |
